    Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate

    Ask Lasest Price
    Brand Name : TOBO/TPCO/TISCO/VALIN/METAL
    Model Number : Incoloy 625 UNS N06625
    Certification : ISO/PED/TUV/SGS/LR/BV
    Price :
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3000 Ton/Tons per Week neogotiation
    Delivery Time : delivery time is according to the actual order
    • Product Details
    • Company Profile

    Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate


    Incoloy 625 UNS N0665 steel plate JIS, AISI, ASTM, GB, DIN, EN

    Quick Details

    Place of Origin:
    Shanghai, China (Mainland)

    Type:
    Nickel plate
    Application:
    Nitrate condenser,Steam heating pipes,etc
    Grade:
    Ni-Cr-Fe alloy
    Ni (Min):
    38
    Powder Or Not:
    Not Powder
    Ultimate Strength (≥ MPa):
    550
    Elongation (≥ %):
    35
    Model Number:
    Incoloy 625
    Brand Name:TOBO

    Packaging & Delivery

    Packaging Details:Wooden Cases
    Delivery Detail:delivery time is according to the actual order

    Specifications

    Incoloy 625 UNS N06625 steel plate:
    1)Size:1000mm x 2000mm
    2)Thk:1mm-60mm
    3)Standard:ASTM B424/ASME SB424,ASTM B906/ASME SB90

    Incoloy 825 UNS NO8825 steel plate :
    1)Size:1000mm x 2000mm
    2)Thk:1mm-60mm
    3)Standard:ASTM B424/ASME SB424,ASTM B906/ASME SB906

    Chemical Composition, %

    CrNiMoCo + NbTaAlTiCFeMnSiPS
    20.00-30.00Remainder8.0-10.01.0 max3.15-4.15.40 max.40 max.10 max5.0 max.50 max.50 max.015 max.015 max

    In what applications is Inconel 625 used?

    · Aircraft ducting systems

    · Aerospace

    · Jet engine exhaust systems

    · Engine thrust-reverser systems

    · Specialized seawater equipment

    · Chemical process equipment

    Fabrication with Inconel 625

    Alloy 625 has excellent forming and welding characteristics. It may be forged or hot worked providing temperature is maintained in the range of about 1800-2150° F. Ideally, to control grain size, finish hot working operations should be performed at the lower end of the temperature range. Because of its good ductility, alloy 625 is also readily formed by cold working. However, the alloy does work-harden rapidly so intermediate annealing treatments may be needed for complex component forming operations. In order to restore the best balance of properties, all hot or cold worked parts should be annealed and rapidly cooled. This nickel alloy can be welded by both manual and automatic welding methods, including gas tungsten arc, gas metal arc, electron beam and resistance welding. It exhibits good restraint welding characteristics.


    ASTM Specifications

    Pipe SmlsPipe WeldedTube SmlsTube WeldedSheet/PlateBarForgingFittingWire
    B444B705B444B704B443B446---

    Mechanical Properties

    Representative Tensile Properties, bar, 1800° F anneal

    Temp° FTensile (psi).2% Yield (psi)Elongation in 2 “ (%)
    70144,00084,00044
    400134,00066,00045
    600132,00063,00042.5
    800131,50061,00045
    1000130,00060,50048
    1200119,00060,00034
    140078,00058,50059
    160040,00039,000117
