    904L Butt Weld Fittings Stainless Steel Equal Tee 1-48 Inch

    Ask Lasest Price
    Brand Name : TOBO
    Model Number : 904L
    Certification : SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
    Payment Terms : T/T, Western Union, D/P, T/T
    Supply Ability : Negotiation
    Delivery Time : 15days
    • Product Details
    • Company Profile

    904L Butt Weld Fittings Stainless Steel Equal Tee 1-48 Inch



    904L Butt Weld Fittings Stainless Steel Equal Tee 1-48 Inch

    Chemical Composition %

    C

    Cr

    Cu

    Mn

    Mo

    Ni

    P

    S

    Si

    Max



    Max



    Max

    Max

    Max

    0.02

    19.0-23.0

    1.0-2.0

    2.0

    4.0-5.0

    23.0-28.0

    0.045

    0.035

    1.0


    SPECIFICATIONS


    ASTM B677, B366
    ASME SB677, SB366

    DESCRIPTION
    904L is a high-alloy austenitic stainless steel with low carbon content. The grade is intended for use under severe corrosive conditions.

    standardized and approved for pressure vessel use in several countries. Structurally, 904

    L is fully austenitic and is less sensitive to precipitation ferrite and sigma phases than conventional austenitic grades with high molybdenum content. Characteristically, due to the combination of relatively high contents of chromium, nickel, molybdenum and copper 904L has good resistance to general corrosion, particularly in sulfuric and phosphoric conditions.


    TENSILE REQUIREMENTS
    KSI 70 KSI 25 KSI can be converted to MPA (Megapascals) by multiplying by 6.895.

    Unit : inch
    Nominal
    Pipe
    Size

    Outside Dia.
    (OD)

    Wall Thickness (T)

    Tees Center To Ends C.M



    Sch.5S

    Sch.10S

    Sch.40S

    Sch.80S


    1/2

    0.840

    0.065

    0.083

    0.109

    0.147

    1.00

    3/4

    1.050

    0.065

    0.083

    0.113

    0.154

    1.13

    1

    1.315

    0.065

    0.109

    0.133

    0.179

    1.50

    1-1/4

    1.660

    0.065

    0.109

    0.140

    0.191

    1.88

    1-1/2

    1.900

    0.065

    0.109

    0.145

    0.200

    2.25

    2

    2.375

    0.065

    0.109

    0.154

    0.218

    2.50

    2-1/2

    2.875

    0.083

    0.120

    0.203

    0.276

    3.00

    3

    3.500

    0.083

    0.120

    0.216

    0.300

    3.38

    4

    4.500

    0.083

    0.120

    0.237

    0.337

    4.13

    5

    5.563

    0.109

    0.134

    0.258

    0.375

    4.88

    6

    6.625

    0.109

    0.134

    0.280

    0.432

    5.63

    8

    8.625

    0.109

    0.148

    0.322

    0.500

    7.00

    10

    10.750

    0.134

    0.165

    0.375

    0.500

    8.50

    12

    12.750

    0.156

    0.180

    0.375

    0.500

    10.00

    14

    14.000

    0.156

    0.250

    0.375

    0.500

    11.00

    16

    16.000

    0.165

    0.250

    0.375

    0.500

    12.00

    18

    18.000

    0.165

    0.250

    0.375

    0.500

    13.50

    20

    20.000

    0.188

    0.250

    0.375

    0.500

    15.00

    24

    24.000

    0.218

    0.250

    0.375

    0.500

    17.00
